Technical Parameters
| Tire Size | 11R22.5 | 11R24.5 | 295/75R22.5 | 295/75R22.5 |
| PR | 16(H) | 16(H) | 14(H) | 16(H) |
| Load Index | 148 / 145M | 149/146M | 144/141M | 146/143M |
| Overall Diameter | 1054mm / 41.5inch | 1104mm / 43.5inch | 1014mm / 39.9inch | 1014mm / 39.9inch |
| Section Width | 279mm / 11.0in | 279mm / 11.0in | 298mm / 11.7in | 298mm / 11.7in |
| Tread Depth | 14mm / 17.6(32nd) | 14mm / 17.6(32nd) | 14mm / 17.6(32nd) | 14mm / 17.6(32nd) |
| Rim | 8.25 | 8.25 | 9.00 | 9.00 |
| Max Load | ||||
| Single | 3150kg / 6940lbs | 3250kg / 7160lbs | 2800kg / 6170lbs | 3000kg / 6610lbs |
| Dual | 2900kg / 6395lbs | 3000kg / 6610lbs | 2575kg / 5675lbs | 2725kg / 6005lbs |
| Pressure | 850kpa / 123psi | 825kpa / 120psi | 760kpa / 110psi | 825kpa / 120psi |
Tread and Construction Details
All-Position Tread Pattern
The KDA-5 tread pattern is designed for commercial all-position use where anti-slip performance, rolling control, and wear stability matter.
- 14mm / 17.6/32nds tread depth
- Multi-sipe layout supports anti-slip performance
- Designed for common commercial truck tire sizes
Sidewall Design
The sidewall design supports traction behavior and helps reduce irregular wear under commercial operating conditions.
- Available in 11R22.5, 11R24.5, and 295/75R22.5
- Load index options listed in the technical table
- Suitable for fleet and dealer inventory needs
Shoulder Ribs and Decoupling Grooves
Decoupling grooves and wider shoulder ribs are designed to help improve irregular wear control.
- Wider shoulder ribs for wear resistance
- Decoupling grooves help manage shoulder stress
- Built for consistent commercial tire performance
Full Tire Profile
The full profile view helps dealers and fleet buyers review the KDA-5 product shape, tread width, and overall commercial tire build.
- Wider tread design
- Four-layer belt structure
- All-position tire for fleet, repair shop, and wholesale use
Product Notes
- Wider tread design with four-layer belt structure.
- Multi-sipe layout supports anti-slip performance.
- Shallow tread design helps reduce rolling resistance.
- Decoupling grooves and wider shoulder ribs help improve irregular wear control.
- Unique sidewall design supports traction and helps reduce irregular wear.
Application
KDA-5 is an all-position commercial truck tire for applications where anti-slip performance, rolling resistance, shoulder wear control, and consistent road contact are important. The model is suitable for fleets, truck tire dealers, repair shops, and wholesale buyers looking for common commercial truck tire sizes.
| Recommended Position | All-position commercial truck use |
| Buyer Type | Fleet operators, truck tire dealers, repair shops, wholesale buyers |
| Commercial Use | Commercial trucks, fleet replacement, dealer inventory, all-position tire programs |
| Main Strength | Anti-slip support, rolling resistance control, irregular wear control, wider shoulder rib design |
Construction and Performance
Wider tread and four-layer belts: built to support commercial truck loads and stable road contact.
Multi-sipe layout: supports anti-slip performance in regular commercial operation.
Shallow tread design: helps reduce rolling resistance for commercial truck applications.
Decoupling grooves and shoulder ribs: help improve irregular wear control across the tread area.
Sidewall design: supports traction behavior and helps reduce irregular wear.
Note: Always confirm tire size, PR, load index, rim fitment, maximum load, and pressure requirements before ordering or installing commercial truck tires.
